Custom Printed Tile Technical Specifications & Performance Data
Custom digitally printed porcelain and ceramic tiles deliver high-resolution imagery and durable performance for architectural, commercial, and public environments. These specifications define the material performance and durability characteristics used when selecting kiln-fired systems for high-stakes projects.
Division 09 – Finishes
- Section 09 30 00 – Tiling: High-definition, kiln-fired porcelain and ceramic tile imagery.
- Section 09 72 00 – Wall Coverings: Custom porcelain mural assemblies for interior and exterior vertical surfaces.
Compliance & Performance Summary
To receive a project-specific 3-Part Specification draft, please contact our technical team.
Choose the Right Custom Tile for Your Application
Compare our custom printed ceramic, porcelain, and glass tile systems by application. Use this guide as a starting point for selecting the appropriate material for walls, floors, wet areas, exterior installations, and pools.
| Custom Tile System | Feature Wall |
Bathroom & Shower Walls |
Kitchen Backsplash |
Countertop | Floor |
Exterior / Outdoor |
Pool |
|---|---|---|---|---|---|---|---|
| Custom Printed Ceramic Tile — Satin Finish | ✓ Suitable | ✓ Suitable | ✓ Suitable | — | — | — | — |
| Custom Printed Ceramic Tile — Matte Finish | ✓ Suitable | ✓ Suitable | ✓ Suitable | — | — | — | — |
| Custom Printed Tumbled Porcelain Tile — Rustic Marble Finish | ✓ Suitable | ✓ Suitable | ✓ Suitable | — | — | — | — |
| Custom Printed Glass Tile — Smooth Finish | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | — | — | — |
| Slip-Resistant Custom Printed Glass Floor Tile | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | — | — |
| Exterior-Rated Custom Printed Porcelain Tile | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable | ✓ Suitable |
Need help selecting the right tile system? Final material selection should consider substrate, installation method, traffic, slip resistance, exposure conditions, and project-specific performance requirements. Tell us about your project and we’ll help determine the appropriate tile system.
Request a Tile Project Review →Material Properties & Testing
| Property | Standard | Porcelain Performance |
|---|---|---|
| Water Absorption | ASTM C373 | ≤ 0.5% (Impervious) |
| Scratch Hardness | MOHS Scale | 7 - 8 (Extremely Durable) |
| Chemical Resistance | ASTM C650 | Resistant to acids, bases, and stains |
| Frost Resistance | ASTM C1026 | Resistant (Exterior/Pool Ready) |
Printing Methods & Design Scale
Screen printing is typically used for designs intended to repeat on individual tiles, such as logos, patterns, or graphic fields. Digitally printed porcelain tiles are used when artwork spans multiple tiles, allowing imagery to align precisely across larger surfaces. Selection of printing method is determined by design scale, repetition, and intended application.
Are kiln-fired tiles permanent?
Yes. Unlike sub-surface or UV-printed tiles, our ceramic pigments are fused with the
glaze at 1,400°F+, creating a permanent bond that will not fade or peel for over 100 years.
Design & Planning Considerations
